Trailer Hub And Drum, 8 On 6-1/2" Bolt Circle, 3,500 lb. Capacity For 1-3/4" To 1-1/4" Tapered Spindle - 1/2 Inch Lugs
SKU
HD-1208-02
List Price:
$146.65
Trailer Hub And Drum, 8 On 6-1/2" Bolt Circle, 3,500 lb. Capacity For 1-3/4" To 1-1/4" Tapered Spindle - 1/2 Inch Lugs
$
112.81
In-Stock
Have a Question ? Talk to a specialist- Live chat or call 800-624-7630
Need help with installation? Locate installers near me
Trailer Hub And Drum, 8 On 6-1/2" Bolt Circle, 3,500 lb. Capacity For 1-3/4" To 1-1/4" Tapered Spindle - 1/2 Inch Diameter Lugs
The center hole (pilot hole) in the wheel needs to be 4-1/2" in diameter to use this hub/drum.
Product Details
12" Hub and Drum has 8 on 6-1/2" bolt circle for 1-3/4" To 1-1/4" tapered spindle for a 5,200lb to 6,000lb axle, hub capacity 3,500 lbs. Includes pressed in outer bearing races.
- For use with 12" x 2" electric or hydraulic brakes.
- Flange diameter is 8-1/2"
- Lugs are 1/2"-20
The center hole (pilot hole) in the wheel needs to be 4-1/2" in diameter to use this hub/drum.
Specifications
| Bolt Pattern | 8 x 6.5 |
|---|---|
| Capacity | 3,500 lbs. |
| Depth | 2-1/2 inch |
| Inside Diameter | 12 inch |
| Thread | 1/2-20 |
