Emergency Hub Repair Kit - 5 x 4.5" Bolt Circle to fit a 1-1/16" straight Spindle, 1,350lb Capacity Per Hub
Have a Question ? Talk to a specialist- Live chat or call 800-624-7630
Need help with installation? Locate installers near me
Emergency Hub Repair Kit - 5 x 4.5" Bolt Circle to fit a 1-1/16" straight Spindle, 1,350lb Capacity Per Hub
Pilot diameter 2.5", flange diameter 5.5", hub inner diameter 1.98" with a maximum tire size of 14"
Product Details
Galvanized Hub - Hub Kit comes complete in their own handy storage box, ready to install on your axle. Simply remove your old hub and replace with this pre assembled and pre greased hub. Comes with dust cap, cotter pin and lug nuts.
This hub is a studded 5 x 4.5" bolt circle to fit a 1-1/16" straight spindle 1,350lb capacity per hub for a 2,200lb axle. Pilot diameter 2.5", flange diameter 5.5", hub inner diameter 1.98" with a maximum tire size of 14".
Specifications
| Brand | Smith |
|---|---|
| Bolt Pattern | 5 x 4.5 |
| Capacity | 1,350 lbs. |
| Outside Diameter | 6.5 inch |
| Thread | 1/2-20 |
